Nitrowise is a cutting-edge spray painting system that employs on-site generated nitrogen instead of compressed air. This technology is seamlessly integrated and can be quickly installed by connecting it to the primary compressed air line, making it ready to use. By utilizing ionized nitrogen-enriched air maintained at a consistent temperature, the painting process is stabilized, enabling better management of process variables for improved control.
Kromavis Nitrowise
-
300
SPECIFICATION SHEET
PERFORMANCE
Pressure [bar]:
6, 7, 8
Nitrogen Production [m3/h]:
For Pressure 6: 10.6 m3/h
For Pressure 7: 12.8 m3/h
For Pressure 8: 15 m3/h
Air Consumption [m3/h]:
For Pressure 6: 27.4 m3/h
For Pressure 7: 32 m3/h
For Pressure 8: 36.6 m3/h
DIMENSIONS
Width [cm]: 80*
Depth [cm]: 65
Height [cm]: 184
Weight [kg]: 280
*This dimension does not include the external filters and the heating pipe.
OTHER
Power Consumption: 1kW
Rated Voltage: 230V
Frequency: 50/60Hz
Nominal Power: 5-10A
Special features include a Nitrowise pipe that allows heating up the flow up to 70°C. There's also an Ionizator that allows charging the flow up to 25kV.
CONNECTIONS
Inlet Size: 1/2” Female
Outlet Size: 13mm (rubber pipe 13-19mm)
Electrical Connection: Type F plug (Schuko plug)
LAN Port
MAINTENANCE
Maintenance is required every 2,000 hours or yearly, primarily for filter substitution.
-
500
SPECIFICATION SHEET
PERFORMANCE
Pressure [bar]
6, 7, 8
Nitrogen Production [m3/h]
For Pressure 6: 17.9 m3/h
For Pressure 7: 22 m3/h
For Pressure 8: 26.2 m3/h
Air Consumption [m3/h]
For Pressure 6: 38 m3/h
For Pressure 7: 45 m3/h
For Pressure 8: 53 m3/h
DIMENSIONS
Width [cm]: 80*
Depth [cm]: 65
Height [cm] 184
Weight [kg]: 280
*This dimension does not include the external filters and the heating pipe.
OTHER
Power Consumption: 1kW
Rated Voltage:230V
Frequency:50/60Hz
Nominal Power: 5-10A
Special features include a Nitrowise pipe that allows heating up the flow up to 70°C. There's also an Ionizator that allows charging the flow up to 25kV.
CONNECTIONS
Inlet Size: 1/2” Female
Outlet Size: 13mm (rubber pipe 13-19mm)
Electrical Connection: Type F plug (Schuko plug)
LAN Port
MAINTENANCE
Maintenance is required every 2,000 hours or yearly, primarily for filter substitution.
-
1000
SPECIFICATION SHEET
PERFORMANCE
Pressure [bar]:
6, 7, 8
Nitrogen Production [m3/h]:
For Pressure 6: 35.4 m3/h
For Pressure 7: 44 m3/h
For Pressure 8: 52.4 m3/h
Air Consumption [m3/h]:
For Pressure 6: 76 m3/h
For Pressure 7: 99 m3/h
For Pressure 8: 106 m3/h
DIMENSIONS
Width [cm]: 80*
Depth [cm]: 65
Height [cm]: 184
Weight [kg]: 300
*This dimension does not include the external filters and the heating pipe.
OTHER
Power Consumption: 1kW
Rated Voltage: 230V
Frequency: 50/60Hz
Nominal Power: 5-10A
Special features include a Nitrowise pipe that allows heating up the flow up to 70°C. There's also an Ionizator that allows charging the flow up to 25kV.
CONNECTIONS
Inlet Size: 3/4” Female
Outlet Size: 13mm (rubber pipe 13-19mm)
Electrical Connection: Type F plug (Schuko plug)
LAN Port
MAINTENANCE
Maintenance is required every 2,000 hours or yearly, primarily for filter substitution.
